AllSheng Auto-Pure 96 Nucleic Acid Extraction System DNA RNA

NEW in box

AutoPure-96 Fully Automated Rotary Nucleic Acid Extraction System is a bench top device for DNA and RNA purification by using magnetic separation technology from different

starting materials, such as blood, cultured cells or bacteria, tissues, cell-free body fluids and plant samples. The AutoPure-96 Fully Automatic Nucleic Acid Extraction System is capable of using magnetic rods to transfer particles through the various purification phases of binding, mixing, washing and elution, offering a solution with minimized hands-on time. The DNA and RNA purification is of high quality and high molecular weight.

Features

1. It is easy to use with 7 inch touch screen

2. Very simple operation (easy to install, operate, maintain) without computer

3. Very fast extraction protocol, 15~40 minutes / cycle depending on sample type and method

4. Universal built-in program for easy using

5. High purity and excellent yield of nucleic acid

6. UV lamp to avoid cross contamination

7. 3 shortcut key to make for easy running, stopping the magnetic beads program

8. Open system can optimize purification proposal according to various magnetic beads kits

9. Drawer design to prevent possible injuries

10. With special plastic consumables to avoid cross contamination

11. Improves workflow, and allows staff to perform other value-added tasks

12. Ensures impurities are removed; improved sample quality leads to better downstream analyses

13. Capable of extracting 1~96 samples per run

14. Alarm for indicating the completion of purification

15. Pause function for emergent stop

Operational advantages

1. High-throughput:

AutoPure-96 can process 96x1ml samples simultaneously

2. Open and multiple functions design can be provided more methods for reagent optimization, and also a reliable choice

3. Touch screen interface and easy operation, parameters can be tuned based on experimental requirements

4. Accurate temperature control system ensures stability of purification performance

5. Patent structure design with center rotary table which makes it occupies smaller area of magnetic rod tip comb, which guaranteed stability and liability (Success rate >99.99%)

Technical Data

Type

AutoPure-96

Throughput

1~96

Process volume

50~1000ul

Collection efficiency

>95%

Magnetic rod number

96

Purification accuracy

100 copy sample positive rate>95%

Stability

CV<5%

Plate types

96 Deepwell plate

Healting for lysis tube

Ambient temperature~120°C

Heating for elution tube

Ambient temperature~120°C

Operation

7 inch color touch screen

Extraction steps

Lysis, Sample binding, Washing and elution

Storage Capacity

more than 100 programs

Protocol Management

Create, edit, delete, protocol mode

Pollution Control

UV light

Lighting

Yes

Extension interface

4 standard USB port, built-in SD card

Exhaust

Fan

Power Supply

450W

Dimensions

560×620×500mm

Weight

54Kg

The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, I will verify your status as an authorized purchaser of this item before shipping of the item."

We strongly recommend that you get proper certification prior to use and get the unit completely checked out.

Item has been cleaned and handled in accordance with the manufacturer's instructions.
